Standard POF shrink zaj duab xis yog sib xws nrog ob phau ntawv thiab tag nrho cov semi-auto, puv-auto ntim tshuab, thiab yog dav siv nyob rau hauv ntau yam kev lag luam xws li kev tu tus kheej thiab tsev neeg, tshuaj pleev ib ce, tshuaj, ntawv & luam tawm, phau ntawv, khoom ua si, khw muag khoom. & e-lag luam thiab lwm yam Raws li POF yog FDA pom zoo cov khoom siv rau kev sib cuag nrog cov zaub mov ncaj qha, nws kuj tuaj yeem siv rau hauv kev lag luam khoom noj thiab dej haus.
Nta
-Shrinkage tus nqi yog ruaj khov nyob rau hauv lub ntim kev kawm
- Muaj zog sealing, tensile thiab nruj pob
- Daim ntawv thov dav, haum rau cov ntawv thov zaub mov
- Khw muag khoom npaj kom pom tseeb thiab gloss
- Yooj yim rau siv
- Thickness muaj (10micron, 12micron, 15micron, 19micron, 25micron, 30micron, 38micron)
Standard Polyolefin Shrink Zaj duab xis
Standard POF Shrink Zaj duab xis
POF Shrink Zaj duab xis
Polyolefin yog ib pawg ntawm hydrocarbons, piv txwv li cov tebchaw uas muaj hydrogen [H] thiab carbon [C] atoms.Nws yog feem ntau muab tau los ntawm cov roj av lossis los ntawm cov khoom siv qis-molecular-qhov hnyav ntawm cov roj av.Polyolefin shrink zaj duab xis yog qhov ruaj khov, ntau yam thiab pheej yig.Nws yog crystal ntshiab thiab gloss, uas ua rau lub txee zoo meej.Nws muaj qhov ua haujlwm zoo heev, uas pab tiv thaiv cov khoom tsis tu ncua thoob plaws hauv nws cov khoom siv hluav taws xob.Nws kuj muaj lub zog sealing siab heev, vim tias nws muaj peev xwm tsim tau ib qho tamper-pov thawj foob los tiv thaiv cov khoom.
Khoom:
SWD-01 POF Shrink Zaj duab xis Standard
|
|
|
|
|
TEST NTAWV | UNIT | ASTM TEST | TSEEM CEEB |
|
|
TUB NTXHAIS | 10 awm | 12 awm | 15 awm | 1 9 awm | 25 awm | 30 awm | 38 awm |
|
|
OPTICAL |
|
|
HUAB TAIS | % | D1003 | 2.2 | 2.4 | 2.6 | 3.2 | 3.9 | 4 | 4.2 |
|
|
Kev paub meej | % | D1746 | 98.5 | 98.5 | 98 | 97 | 95 | 92 | 91.5 |
|
|
GLOSS @45 ° C | % | d2457 ua | 86 | 85.5 | 87.5 | 84.5 | 82.2 | 81.5 | 80.5 |
|
|
SHRINKAGE PROPERTIES |
|
|
FREE SHRINKAGE @120 ℃ | MD | % | d2732 ua | 58 | 57 | 57 | 56 | 56 | 56 | 55 |
|
|
TD | 61 | 61 | 61 | 61 | 60 | 60 | 57 |
|
|
TENSILE |
|
|
Lub zog tensile (MD) | N / hli 2 | d882 ua | 115 | 115 | 115 | 110 | 110 | 110 | 110 |
|
|
Lub zog tensile (TD) | 115 | 115 | 115 | 110 | 110 | 110 | 110 |
|
|
ELONGATION (MD) | % | 100 | 100 | 100 | 110 | 110 | 110 | 110 |
|
|
ELONGATION (TD) | 100 | 100 | 100 | 110 | 110 | 110 | 110 |
|
|
LUB SIJ HAWM |
|
|
MD | g | D1922 | 9.2 | 10.5 | 13.5 | 18.0 | 23.5 | 28.5 | 31.0 |
|
|
TD | 9.5 | 10.0 | 12.6 | 17.5 | 22.5 | 28.0 | 29 |
|
|
TSEEM CEEB |
|
|
HOT WIRE SEAL (MD) | N / hli | F88 | 0.62 | 0.75 | 0.89 | 1.04 | 1.25 | 1.43 | 1.67 |
|
|
HOT WIRE SEAL (TD) | 0.65 | 0.78 | 0.91 | 1.06 | 1.31 | 1.52 | 1.69 |
|
|
COF (Zoo rau FILM) |
|
|
DYNAMIC | ua m d | D1894 | 0.23 | 0.23 | 0.22 | 0.24 | 0.22 | 0.22 | 0.23 |
|
|
CEEB TOOM: Muaj cov ntaub ntawv tseem ceeb rau Sunward POF shrink zaj duab xis thiab tsis yog siv rau kev txwv kev txwv.
Peb cov khoom tau txais lub koob npe nrov hauv tsev thiab thoob ntiaj teb.Cov txheej txheem kev tswj hwm nruj nruj yog siv los ntawm txhua kauj ruam hauv cov txheej txheem tsim khoom los ntawm cov khoom siv raw khoom thiab pob.Peb nrhiav kev tsim kom muaj kev sib raug zoo nrog cov neeg siv khoom kom muaj txiaj ntsig zoo dua yav tom ntej.Yog tias koj txaus siab rau ib qho ntawm peb cov khoom, thov hu rau peb dawb!
