Availability: | |
---|---|
Part | Details | Technical parameter description |
Power/power | 220V 50/60Hz ≤4kw | |
sealing system | heat source | Using stainless steel heating tube, long service life |
Sealing knife | It adopts anti-stick and high-temperature resistant alloy sealing knife, and the outside of the knife is coated with Teflon non-stick film. | |
Sealing knife temperature control | Adopting Yatai digital display temperature controller and imported thermal response control, the air temperature is adjustable from 0-300`C | |
Sealing knife size | The width is adjustable by manual wheel, and the height is 5-150mm; Sealing cutter size; L unlimited × W 30 0mm | |
Sealing knife protection | Made from Taiwan Taibang. Effectively prevent mis-sealing of packaging objects | |
cylinder | Taiwan Airtac cylinder controls sealing and cutting, Ensure the sealing is firm and stable, with low noise during sealing | |
Conveyor system | belt | Germany Siegelin PU conveyor belt |
Motor | Taiwan's "GPG" ensures smooth transportation | |
Detection | Using Japanese "Omron" photoelectric sensor to accurately and sensitively detect product delivery and stop | |
recycling system | Motor | Taiwan's "GPG"ensures accurate and uniform waste recycling |
sensory switch | Use Taiwan Taibang to accurately control the recycling time of waste materials | |
Film feeding system | Motor | Taiwan's "GPG" ensures smooth film delivery |
sensory switch | Taibang proximity switch accurately controls the length of film feeding | |
PLC | FATEK | |
contactor | French SCHNEIDER | |
Intermediate relay | Schneider | |
thermostat | Yatai | |
emergency switch | Siemens, Germany | |
hole punch | Multiple hole punches to quickly expel the air inside the bag when shrinking | |
Mechanical component materials | Carbon steel is spray-coated, and key parts are made of stainless steel plates and aluminum profiles to ensure a solid structure. | |
Mechanical Dimensions | 2200 * 90 0*1 515 (L*W*H specific dimensions are subject to the actual object) | |
packaging speed | Depending on the size of the packaging (10-20 pieces/minute) | |
air pressure | 5.5KG/cm2 | |
Surface treatment requirements | Anti-corrosion structural material surface sprayed or nickel plated |
Main performance
● Advanced single-side sealing technology, continuous sealing, unlimited product length. P OF fully enclosed packaging is particularly suitable for long, wide and heavy products , and is especially designed for small products such as books and electronic products.
● Using Taiwan FATEK Program controller realizes the integration of machinery, electricity and gas
● Using the most advanced edge sealing device, the packaging length is not limited. Double sealing and cutting can also be selected according to product specifications. The waste film produced during packaging is automatically rolled up.
● The side sealing line can be adjusted to the required position according to the height of the product packaging . Achieves excellent sealing strength
● Suitable for P OF shrink film with thickness of 0.0 1 ~ 0. 02 mm
● According to the needs of customers, front and rear conveying, output mechanisms and color film positioning functions can be added.
● Humanized operation interface, convenient for operators to use
Standard main components (selection of electronic control system)
● PLC FATEK (Taiwan)
● HIM Yonghong (FATEK) (Taiwan)
● Frequency converter Zhongchen (China)
● GPG ( Taiwan)
● Cutter push cylinder AirTAC (Taiwan)
● Solid state relay BEDOOK (China)
● Push button switch Siemens (Germany)
● Contactor Schneider (France)
● Contactor Schneider (France)
All components of the equipment must adapt to the on-site temperature environment, -2℃~58℃.
